Spare Parts/Accessories
10.2 CompactFlash Card
NCU 7x0.2
Manual, 02/2011, 6FC5397-0AP20-0BA0
105
10.2.2 Inserting the CompactFlash card
Proceed as follows
NOTICE
ESD: you must discharge yourself at the cabinet or ground terminal before touching the
CompactFlash Card.
Please proceed as follows:
1. Switch off the power supply.
2. Gently insert the new CompactFlash Card into the plug-in slot until it clicks into place.
When properly installed, the card does not extend beyond the housing.
3. Switch the power supply on again.
Figure 10-3 Inserting the CompactFlash card
