Mounting

6.3 Mounting the control unit on the rear wall of the control cabinet

NCU 7x0.2

Manual, 02/2011, 6FC5397-0AP20-0BA0

41

3. Tighten up the three screws on the clip again.

4. Mount the top and bottom of the control unit directly on the rear wall of the control cabinet

with two M6 screws (6 Nm).

0RXQWZLWK0VFUHZV

Figure 6-2 Mounting the control unit without spacers
