High-side switches serve as output drivers, which switch 24 V to the lamps and which limit the
current when a short-circuit occurs.
Connector designation: X130
Connector type: 10-pin male connector
Maximum cable length: 2 m
Table 6-4 Assignment of connector X130
Pin Name Type Meaning
1 S14 I Ext. key S14
2 S15 I Ext. key S15
3 S16 I Ext. key S16
4 S17 I Ext. key S17
5 P24 V 24 V reference potential
6 H14 O LED H14 ext. key
7 H15 O LED H15 ext. key
8 H16 O LED H16 ext. key
9 H17 O LED H17 Ext. key
10 M V 24 V reference potential
Individual wiring, keys (X150)
The individual wiring interface X150 facilitates an external evaluation of the states of keys S1 to
S4 and S7 to S10. Each of the outputs has a maximum 0.15 A rating.
High-side switches serve as output drivers, which limit the current when a short circuit occurs.
Connector designation: X150
Connector type: 9-pin male connector
Maximum cable length: 10 m
Table 6-5 Assignment of connector X150
Pin Name Type Meaning
1 S01_ext O NC contact signal S01
2 S02_ext O NC contact signal S02
3 S03_ext O NC contact signal S03
4 S04_ext O NC contact signal S04
5 S07_ext O NC contact signal S07
6 S08_ext O NC contact signal S08
7 S09_ext O NC contact signal S09
8 S10_ext O NC contact signal S10
9 M V 24 V reference potential
Connecting up
6.3 Pin assignment of the interfaces
Machine Push Button Panel: MPP 1500D / MPP 1500E
38 Equipment Manual, 04/2021, A5E50753610B AA
