Technical data
8
8.1 MPP 1500D/E
Safety
Protective class according to EN 50178 III; PELV
Degree of protection according to EN 60529
Front: IP54
Rear: IP00
Approvals CE / EAC
Electrical data
Overvoltage category Secondary circuit supplied from primary circuits up to Cat. III, 300 V AC
1)
Power supply
24 V DC (20.4 V ... 28.8 V)
Power consumption, typ.
(without external illuminated customer keys)
Device 10 W
Handwheels 2 x 0.5 W
Total 11.8 W
Power consumption, max.
(incl. external illuminated customer keys and hand‐
held unit)
60 W
Mechanical data
Dimensions of the MPP 1500D
Dimensions W x H (mm) 416.5 x 155
Mounting depth
2)
80 mm
Dimensions of the MPP 1500E
Dimensions W x H (mm) 398 x 165
Mounting depth
2)
80 mm
Weight (kg) approx. 2.5
Max. vertical mounting position ≤ 60°
Tightening torques, max. Tension jacks: 0.4 Nm
M3 standard: 0.8 Nm
M3 weld studs/sleeves: 0.5 Nm
M4 standard: 1.8 Nm
M4 weld studs/sleeves: 1 Nm
M5 standard: 3 ...6 Nm
M5 weld studs/sleeves: 1.5 Nm (ground: 3 Nm, hold lower nut in place)
Climatic ambient conditions
Cooling Through natural convection
Condensation, splash water and ice formation Not permitted
Supply air Without aggressive gases, dusts and oils
Max. installation altitude (use and operation) Up to 1000 m without derating
From 1000 m to 4000 m with linear ambient temperature derating,
-0.5 K per 100 m
Machine Push Button Panel: MPP 1500D / MPP 1500E
Equipment Manual, 04/2021, A5E50753610B AA 53
