MPP 1500E Machine Push Button Panel
The MPP 1500E Machine Push Button Panel is shown in the following drawing.
PP
PP
PP



Figure 3-2 Views of the MPP 1500E
The MPP 1500E Machine Push Button Panel comprises:
① COM board (APCB COM IE)
② Handheld unit connection and key module (APCB HT)
③ Control panel
3.4 Interfaces
Interfaces of the MPP 1500D/E
The interfaces relevant for cabling the control desk are located on the rear side of the Machine
Push Button Panel.
