Siemens SINUMERIK MPP 1500D - Assembled PCB COM Board (APCB COM IE)

Rapid traverse override rotary switch
Connector designation: X32
Connector type: 2 x 5-pin male connector, according to EN 60603-13 with coding
Table 6-6 Assignment of connector X32
Pin Name Type Meaning
1 N.C. - Not assigned
2 N.C. - Not assigned
3 M I Ground
4 N.C. - Not assigned
5 P5 V 5 V reference potential
6 OV_SP16 I Override rotary switch position / weighting 16
7 OV_SP8 I Override rotary switch position / weighting 8
8 OV_SP4 I Override rotary switch position / weighting 4
9 OV_SP2 I Override rotary switch position / weighting 2
10 OV_SP1 I Override rotary switch position / weighting 1
6.3.2 Assembled PCB COM board (APCB COM IE)
The following de󹪝nition applies.
B Bidirectional
O Output
V Voltage (supply voltage)
I Input
Ethernet connector assignment
Connector designation: X20, X21
Connector type: RJ45 socket
Maximum cable length: 100 m
Table 6-7 Assignment of connectors X20, X21
Pin Name Type Meaning
1 TX+ I Transmit +
2 TX- I Transmit -
3 RX+ O Receive +
4 N.C. - Not assigned
5 N.C. - Not assigned
6 RX- O Receive -
Connecting up
6.3 Pin assignment of the interfaces
Machine Push Button Panel: MPP 1500D / MPP 1500E
Equipment Manual, 04/2021, A5E50753610B AA 39
