Pin Name Type Meaning
7 N.C. - Not assigned
8 N.C. - Not assigned
Rotary switch feedrate override
Connector designation: X30
Connector type: 2 x 5-pin male connector, according to EN 60603-13 with coding
Table 6-8 Assignment of connector X30
Pin Name Type Meaning
1 N.C. - Not assigned
2 N.C. - Not assigned
3 M V Ground
4 N.C. - Not assigned
5 P5 V 5 V supply
6 OV_VS16 I Override rotary switch position / weighting 16
7 OV_VS8 I Override rotary switch position / weighting 8
8 OV_VS4 I Override rotary switch position / weighting 4
9 OV_VS2 I Override rotary switch position / weighting 2
10 OV_VS1 I Override rotary switch position / weighting 1
Rotary spindle override switch
Connector designation: X31
Connector type: 2 x 5-pin male connector, according to EN 60603-13 with coding
Table 6-9 Assignment of connector X31
Pin Name Type Meaning
1 N.C. - Not assigned
2 N.C. - Not assigned
3 M V Ground
4 N.C. - Not assigned
5 P5 V 5 V supply
6 OV_SP16 I Override rotary switch position / weighting 16
7 OV_SP8 I Override rotary switch position / weighting 8
8 OV_SP4 I Override rotary switch position / weighting 4
9 OV_SP2 I Override rotary switch position / weighting 2
10 OV_SP1 I Override rotary switch position / weighting 1
Optional customer keys (X51/X52/X55)
Only connect switches via connectors X51, X52 and X55 (passive inputs).
Connecting up
6.3 Pin assignment of the interfaces
Machine Push Button Panel: MPP 1500D / MPP 1500E
40 Equipment Manual, 04/2021, A5E50753610B AA
