Control panel
① Feedrate override
② S13 EMERGENCY STOP
③ S113 EMERGENCY STOP override
④ XS12 Connection for handheld unit
⑤ EKS Electronic Key System
⑥ Ground connection M5 ground connection for MPP 1500D/E
Handheld unit connection and key module (APCB HT / HT board)

① X100 24 V power supply of the MPP 1500D/E
② X140 Individual wiring, LED
③ X150 Individual wiring, keys
Description
3.4 Interfaces
Machine Push Button Panel: MPP 1500D / MPP 1500E
Equipment Manual, 04/2021, A5E50753610B AA 23
