<REF POINT>
Approach reference point.
Inc <VAR>(Incremental Feed Variable)
Incremental mode with variable increment size.
...
Inc (incremental feed)
Incremental mode with predefined increment size of
1, ..., 10000 increments.
Machine manufacturer
A machine data code defines how the increment value is inter‐
preted.
Traversing axes with rapid traverse override and coordinate switchover
...
Axis keys
Selects an axis.
...
Direction keys
Select the traversing direction.
<RAPID>
Traverse axis in rapid traverse while pressing the direction key.
<WCS MCS>
Switches between the workpiece coordinate system (WCS) and machine
coordinate system (MCS).
Spindle control with override switch
<SPINDLE STOP>
Stop spindle.
<SPINDLE START>
Spindle is enabled.
Introduction
2.3 Machine control panels
Milling
38 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
