7.4 Digital inputs/outputs
X122 pin assignment
Pin Signal name Meaning
1 DI0 DI0 Digital input 0
2 DI1 DI1 Digital input 1
3 DI2 DI2 Digital input 2
4 DI3 DI3 Digital input 3
5 DI16 DI16 Digital input 16
6 DI17 DI17 Digital input 17
7 M2 MEXT2 Ground for pins 1...6
8 P1 P24EXT1 +24 V power supply
9 IO8 DI/DO8 Digital input/output 8
10 IO9 DI/DO9 Digital input/output 9
11 M1 MEXT1 Ground for pins 9, 10, 12, 13
12 IO10 DI/DO10 Digital input/output 10
13 IO11 DI/DO11 Digital input/output 11
14 M1 MEXT1 Ground for pins 9, 10, 12, 13
X132 pin assignment
Pin Signal name Meaning
1 DI4 DI4 Digital input 4
2 DI5 DI5 Digital input 5
3 DI6 DI6 Digital input 6
4 DI7 DI7 Digital input 7
5 DI20 DI20 Digital input 20
6 DI21 DI21 Digital input 21
7 M2 MEXT2 Ground for pins 1...6
8 P1 P24EXT1 +24 V power supply
9 IO12 DI/DO12 Digital input/output 12
10 IO13 DI/DO13 Digital input/output 13
11 M1 MEXT1 Ground for pins 9, 10, 12, 13
12 IO14 DI/DO14 Digital input/output 14
13 IO15 DI/DO15 Digital input/output 15
14 M1 MEXT1 Ground for pins 9, 10, 12, 13
Interface description
7.4 Digital inputs/outputs
PPU 1740
Equipment Manual, 01/2019, A5E47615272B AA 71
