Siemens SINUMERIK ONE PPU 1740 Series User Manual

8.1.6 Technical Data
Technical data of the NX10.3 / NX15.3
Parameter Value
Input voltage
Permissible range
24 V DC
20.4 V - 28.8 V DC
Current
(without DRIVE-CLiQ and digital outputs)
0.8 A
Inrush current 1.6 A
PE/ground connection At the housing with screw M5/3 Nm
Number of axes, maximum
● NX10.3:
● NX15.3:
3
6
Digital inputs 6
Digital inputs/outputs parameterizable 4
Cooling Open-circuit ventilation
Pollution degree in acc. with EN 61800-5-1 2
Protection class in acc. with EN 61800-5-1 III (DVC A, PELV)
Degree of protection in acc. with EN 60529 IP20
Approvals CE, cULus
Relative humidity:
● Storage
● Transport
● Operation
5 ... 95 %
5 ... 95 %
5 ... 95 %
Ambient temperature:
● Storage
● Transport
● Operation
-25 ... +55 °C
-40 ... +70 °C
0 ... +55 °C
Dimensions:
● Width
● Height
● Depth
25 mm
414 mm
272 mm
Weight, approx. 2.58 kg
Connectable components
8.1 NX10.3 / NX15.3
PPU 1740
Equipment Manual, 01/2019, A5E47615272B AA 91
