7.5 DRIVE-CLiQ
7.5.1 DRIVE-CLiQ interface
X100 - X103 pin assignment
PIN Signal name Signal type Meaning
1 TXP O Transmit data +
2 TXN O Transmit data -
3 RXP I Receive data +
4 -- -- Reserved
5 -- -- Reserved
6 RXN I Receive data -
7 -- -- Reserved
8 -- -- Reserved
A -- -- Reserved
B -- -- Reserved
Use
DRIVE-CLiQ interfaces are used to connect SINAMICS S120 components to the PPU.
It has the following properties:
● Components can be independently expanded
● Automatic detection of components by the PPU
● Standardized interfaces to all components
● Uniform diagnostics down to the components
● Complete service down to the components
Cable specification for X100 - X103
Feature Version
Connector type RJ45 socket with 180° cable outlet
Cable type MOTION-CONNECT
Article number
Max. cable length 70 m
Note
Interfaces X100 to X103
The interfaces X100 to X103 provide power supply voltage 24V/450mA to connect encoder/
measuring systems like SME.
Interface description
7.5 DRIVE-CLiQ
PPU 1740
Equipment Manual, 01/2019, A5E47615272B AA 77
