8.1.5 Connecting
X124 power supply pin assignment
Connector designation: X124
Connector type: Screw terminal 2
Max. connectable cross-section: 2.5 mm
2
Pin Signal name Meaning
1 + (Voltage input) Electronics power supply
2 + (Voltage input) Electronics power supply
3 M (Voltage output) Ground
4 M (Voltage output) Ground
Note
The two terminals "+" and "M" are jumpered in the connector and not in the device. This ensures
that the supply voltage is looped through.
Parameter Value
Voltage 24 VDC (20.4 V - 28.8 V)
Current consumption Max. 0.8 A (without load)
Max. current via the jumper in the connector 20 A at 55° C
Note
Current consumption
The current consumption increases by the current consumption of DRIVE-CLiQ and the digital
outputs.
X122 digital inputs/outputs pin assignment
Connector designation: X122
Connector type: Spring-loaded terminal 1
Max. connectable cross-section: 0.5 mm
2
Pin Signal name Meaning
1 DI0 Digital input 0
2 DI1 Digital input 1
3 DI2 Digital input 2
4 DI3 Digital input 3
Connectable components
8.1 NX10.3 / NX15.3
PPU 1740
88 Equipment Manual, 01/2019, A5E47615272B AA
