1 Technical Description
1.6 Technical Data
1.6.3 Technical Data of the Options Modules
Manual
100
SIP ART DR24 6DR2410
C79000-G7476-C153-03
6DR2800-8V UNI module Analog inputs AE4 (slot 2), AE5 (slot 3)
Analog inputs AE4, AE5
mV
1)
TC
2)
Pt100 R R
Slot 2, 3
°C R ≤ 600 Ω R ≤ 2,8 kΩ
Range start MA
Range end ME
≥-175 mV
≤+175 mV
≥-175 mV
≤+175 mV
≥-200 °C
≤+850 °C
≥0 Ω
≤600 Ω
≥0 Ω
≤2,8 kΩ
Span Δ =ME-MA parameterizable 0 to Δma x
Min. recommended span 5mV 5mV 10 K 30 Ω 70 Ω
Measuring transducer fault mes-
sage MUF
-2.5 % ≥ MUF ≥ 106.25 %
3)
Input current ≤1 μA ≤1 μA -- -- --
Supply current -- -- 400 μA 400 μA 140 μA
Potential isolation
Test voltage 500 V AC
Perm. common mode voltage ≤50 V UC ≤50 V UC -- -- --
Line resistance
2L RL1+RL4 ≤1kΩ ≤300 Ω ≤50 Ω
3L: (RL1) = RL2 = RL4 -- -- ≤50 Ω
4L: RL1 to RL4 -- -- ≤100 Ω
Break signaling without ≥500 to
550 Ω
all
terminals
Break between
terminal 2--3
Error
Transmission ±10 μV ±10 μV ±0.2 K ±60 mΩ ±200 mΩ
Linearity ±10 μV ±10 μV ±0.2 K ±60 mΩ ±200 mΩ
Resolution/noise ±5 μV ±2 μV ±0.1 K ±30 mΩ ±70 mΩ
Common mode ±1 μV/10 V ±1 μV/10 V
Internal reference point -- ±0.5 K -- -- --
Temperature error
Transmission
±0.05 %/10 K
3)
Internal reference point -- ±0.1K/10K
Statistical destruction limit ±35 V ±35 V -- -- --
Cycle time 100 ms 200 ms 300 ms 200 ms 200 ms
Filter constant adaptive <1.5 s <2 s <2 s <1.5 s <1.5 s
1)
20 mA, 10 V with measuring range plug 6DR2805-8J
2)
Types see CAE menu, internal reference point (pluggable terminal block) 6DR2805-8A
3)
Referenced to parameterizable span D = ME - MA
Table 1 -5 Technical data for UNI module 6DR2800--8V
