Design and Functional Principle
24
SIP ART PS2 Manual
A5E00074631-01
A
D
A
D
1
3 V
I
W+
I
W-
W
y
0
x
0
+
_
W
x
+U
A1 A2
6
2
_
y
+
y
U
U
I
5
4
3
Zuluft
p
Z
Abluft
p
2
p
1
Abluft
8
9
p
2
p
1
p
1
_
+
p
2
p
1
A1 A2
7
II
HART
BE1
Micro-
controller
BE2
+24 V
+5 V
Exhaust air
Exhaust
air
Supply air
stroke
stroke
1 Motherboard with microcontroller and input circuit
2 Control panel with LC-dis play and momentary action switch
3 Piezo--valve unit, always built--in
4 Valve unit with double action positioner always built--in
5 Iy-module for positioner SIPART PS2
6 Alarm module for three alarm outputs and one digital input
7 SIA-module (Slot Initiator-Alarm-module)
8 Spring--loaded pneumatic actuator (single action)
9 Spring--loaded pneumatic actuator (double action)
Figure 2-9 Block diagram of the electro --pneumatic positioner, functional diagram
.
NOTE
Alarm module (6) and SIA module (7) can only be used alternatively.

Siemens SIPART PS2 6DR5010 Series Specifications

General

Enclosure Rating	IP66/NEMA 4X
Communication Protocol	HART
Housing Material	Aluminum or stainless steel
Type	Electropneumatic
Input Signal	4-20 mA
Supply Pressure	1.4 to 7 bar
Stroke Range	3 to 130 mm
Temperature Range	-40°C to +80°C
Ambient Temperature Range	-40°C to +80°C
Mounting	Linear or rotary actuators
Power Supply	4-20 mA loop powered
