Preparing for Operation
34
SIP ART PS2 Manual
A5E00074631-01
90
79,5
20,5
3x
G1/4or
1/4” NPT
9,5
9
50
14
12
25
29,5
58,75
82
Thread depth 5.5
M4
5 5
10
2xM6
5,3
9,5
3,5
Figure 3-2 Dimensional drawing terminal strip for plastic housing
11,2
23
58
50x4xM6
M8, 9 deep
88,5
8
All air connections
G 1/4 or 1/4” NPT
9 deep
182
34,5
27,5
84
59
29,5
29
15
96,6
13,5
65
h9
1
14,5
7
38,5
Y1
E
6,5
12
29,5
14
7
2
Y1
PZ
M20 x 1.5 or NPT-adapter
Figure 3-3 Dimensional drawing version metal housing 6DR5xx1

Siemens SIPART PS2 6DR5010 Series Specifications

General

Enclosure Rating	IP66/NEMA 4X
Communication Protocol	HART
Housing Material	Aluminum or stainless steel
Type	Electropneumatic
Input Signal	4-20 mA
Supply Pressure	1.4 to 7 bar
Stroke Range	3 to 130 mm
Temperature Range	-40°C to +80°C
Ambient Temperature Range	-40°C to +80°C
Mounting	Linear or rotary actuators
Power Supply	4-20 mA loop powered
