Siemens SIPART PS2 series Hardware Installation Manual

Installing/mounting
3.1 Basic Safety Instructions
Venting Gauge Block Installation Instructions
Hardware Installation Manual, 12/2014, A5E34388399-AD
13
3.1.2
Unsuitable Compressed Air
NOTICE
Caution
Use of process fluids other than instrument air is not recommended. No claim is made as to
the suitability of this product for use with other process fluids.
3.1.3
Prior to working on the control valve
CAUTION
Please note the following before working on the control valve and when attaching the
positioner
Danger of injury.
• Prior to working on the control valve, you must move the control valve into a completely
unpressurized. Proceed as follows:
– Depressurize the actuator chambers.
– Switch off the supply air PZ.
– Lock the valve in its position.
• Make sure that the valve has reached the unpressurized state.
• If you interrupt the pneumatic auxiliary power to the positioner, the unpressurized
position may only be reached after a certain waiting time.
• When mounting, observe the following sequence imperatively to avoid injuries or
mechanical damage to the positioner/mounting kit:
– Mount the positioner mechanically.
– Connect the electrical auxiliary power supply.
– Connect the pneumatic auxiliary power supply.
–
Commission the positioner.
WARNING
Mechanical impact energy
In order to ensure the degree of protection of the housing (IP66), protect the housing
versions of the positioners listed here from mechanical impact energy:
• 6DR5..3; not greater than 2 Joule
• 6DR5..0; not greater than 1 Joule
• 6DR5..1 with inspection window; not greater than 1 Joule

Siemens SIPART PS2 series Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Type	Electropneumatic
Input Signal	4-20 mA
Stroke Range	3 to 200 mm
Rotary Range	30 to 100°
Mounting	Linear or rotary actuators
Certifications	ATEX, IECEx, FM, CSA
