Siemens SIPART PS2 Compact Operating Instructions

SIPART PS2 (6DR5...)
A5E03436620-06, 04/2015
43
Explosion protection in accordance with
ATEX/IECEx
FM/CSA
Position feedback module (already fitted
or can be retrofitted)
•
Already fitted:
6DR5ayb-0cde
f
-g.Ah-Z ...
with the data (f = 1 or 3)
• Can be retrofitted 6DR4004-6J
a = 0 or 2 applies: T4: -30 ≤ T
a
≤ +80 °C (-22 ≤ T
a
≤ +176 °F)
a = 5 or 6 applies: T4: -20 ≤ T
a
≤ +75 °C (-4 ≤ T
a
≤ +167 °F)
•
Already fitted and can be retrofitted:
6DR5
a
yb-0
c
de
f
-g.Ah-Z
M40
with the data (a = 0 or 2) and (c = E)
and (f = 1 or 3)
T4: -40 ≤ T
a
≤ +80 °C (-40 ≤ T
a
≤ +176 °F)
Option modules
• Non contacting sensor (NCS)
6DR4004-6N..-0-...
T4: -40 ≤ T
a
≤ +90 °C (-40 ≤ T
a
≤ +194 °F)
T6: -40 ≤ T
a
≤ +70 °C (-40 ≤ T
a
≤ +158 °F)
T4: -40 ≤ T
a
≤ +85 °C (-40 ≤ T
a
≤ +185
°F)
T6: -40 ≤ T
a
≤ +70 °C (-40 ≤ T
a
≤ +158
°F)
• External position detection system
C73451-A430-D78
T4: -40 ≤ T
a
≤ +90 °C (-40 ≤ T
a
≤ +194 °F)
T6: -40 ≤ T
a
≤ +60 °C (-40 ≤ T
a
≤ +140 °F)
T4: -40 ≤ T
a
≤ +85 °C (-40 ≤ T
a
≤ +185
°F)
T6: -40 ≤ T
a
≤ +60 °C (-40 ≤ T
a
≤ +140
°F)
Maximum permissible ambient temperature ranges with type of protection Ex t
Explosion protection in accordance with
ATEX/IECEx
FM/CSA
With and without HART
• 6DR5
a
yb-0
c
def-g.Ah-Z ...
with the data (a = 0 or 2) and (c = D or
K)
-30 ≤ T
a
≤ +80 °C (-22 ≤ T
a
≤ +176 °F)
PROFIBUS PA or FOUNDATION
Fieldbus
•
6DR5ayb-0cdef-g.Ah-Z ...
with the data (a = 5 or 6) and (c = D or
K)
-20 ≤ T
a
≤ +75 °C (-4 ≤ T
a
≤ +167 °F)
Position feedback module (already fitted
or can be retrofitted)
• Already fitted:
6DR5ayb-0
c
de
f
-g.Ah-Z ...
with the data (c = D or K) and (f = 1 or
3)
•
Can be retrofitted 6DR4004-6
a = 0 or 2 applies: -30 ≤ T
a
≤ +80 °C (-22 ≤ T
a
≤ +176 °F)
a = 5 or 6 applies: -20 ≤ T
a
≤ +75 °C (-4 ≤ T
a
≤ +167 °F)
7.2 Natural gas as actuator medium
Introduction
Note when using an actuator with natural gas that this can escape at the following points:
● At the exhaust air outlet with sound absorber.
● At the enclosure vent.
● At the control air outlet near the pneumatic connections.

Siemens SIPART PS2 Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Communication Protocols	HART, PROFIBUS PA, FOUNDATION Fieldbus
Output Pressure	0 to 100% of supply pressure
Hazardous Area Certification	ATEX, IECEx, FM, CSA
Type	Electropneumatic
Input Signal	4-20 mA
Rotation Angle	30° to 90°
Operating Temperature	-40°C to +80°C
Mounting	Linear and rotary actuators
Air Consumption	Typically less than 0.1 kg/h
