7.5.3 SIA module
Without Ex protection
With Ex protection Ex "ia"
With Ex protection Ex "ic",
"nA", "t"
SIA module
Limit encoder with slotted initiators
and fault message output
6DR4004-8G 6DR4004-6G 6DR4004-6G
2 slotted initiators
• Binary output (limit transmitter) A1: Terminals 41 and 42
•
Binary output (limit transmitter) A2: Terminals 51 and 52
• Connection
2 wire technology in accordance with EN 60947-5-6 (NAMUR), for switching
amplifiers connected on load side
• Signal state High
(not triggered)
> 2.1 mA
•
Signal state Low (triggered)
< 1.2 mA
•
2 slotted initiators
Type SJ2-SN
• Function
NC contact (NC, normally closed)
• Connecting to circuits with the
following peak values
Nominal voltage 8 V;
current consumption:
≥ 3 mA (limit not
activated),
≤ 1 mA (limit activated)
U
i
= DC 15 V
I
i
= 25 mA
P
i
= 64 mW
"ic":
U
i
= DC 15 V
I
i
= 25 mA
"nA":
U
n
≤ DC 15 V
P
n
≤ 64 mW
Effective internal capacitance
-
C
i
= 41 nF
C
i
= 41 nF
Effective internal inductance
-
L
i
= 100 μH
L
i
= 100 μH
1 fault message output
•
Binary output: Terminals 31 and 32
• Connection
At switching amplifier in accordance with EN 60947-5-6: (NAMUR), U
H
= 8.2 V, R
i
=
1 kΩ).
• Signal state High
(not triggered)
R = 1.1 kΩ > 2.1 mA > 2.1 mA
•
Signal state Low (triggered)
R = 10 kΩ
< 1.2 mA
< 1.2 mA
• Auxiliary power U
H
U
H
≤ DC 35 V
I ≤ 20 mA
- -
• Connecting to circuits with the
following peak values
- U
i
= DC 15 V
I
i
= 25 mA
P
i
= 64 mW
"ic":
U
i
= DC 15 V
I
i
= 25 mA
"nA":
U
n
≤ DC 15 V
P
n
≤ 64 mW
Effective internal capacitance
-
C
i
= 5.2 nF
C
i
= 5.2 nF
Effective internal inductance
-
L
i
= negligibly small
L
i
= negligibly small
Galvanic isolation
The 3 outputs are galvanically isolated from the basic device.
Test voltage
DC 840 V, 1 s

Siemens SIPART PS2 Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Communication Protocols	HART, PROFIBUS PA, FOUNDATION Fieldbus
Output Pressure	0 to 100% of supply pressure
Hazardous Area Certification	ATEX, IECEx, FM, CSA
Type	Electropneumatic
Input Signal	4-20 mA
Rotation Angle	30° to 90°
Operating Temperature	-40°C to +80°C
Mounting	Linear and rotary actuators
Air Consumption	Typically less than 0.1 kg/h
