Siemens SIPART PS2 Compact Operating Instructions

SIPART PS2 (6DR5...)
A5E03436620-06, 04/2015
55
Certificates and approvals
CE conformity The applicable directives and applied standards with their revision levels can
be found in the EC declaration of conformity on the Internet.
Explosion protection
Ex markings
Explosion protection in accordance with
ATEX
Intrinsic safety "ia"
Zone 1:
II 2 G Ex ia IIC T6/T4 Gb
Zone 21:
II 2 D Ex ia IIIC T110°C Db
Intrinsic safety "ic"
Zone 2:
II 3 G Ex ic IIC T6/T4 Gc
Non-sparking "nA"
Zone 2:
II 3 G Ex nA IIC T6/T4 Gc
Permissible ambient temperature
T4: -40 ... +90 °C (-40 ... +194 °F)
T6: -40 ... +60 °C (-40 ... +140 °F)
A Appendix
A.1 Certificate
The certificates can be found on the enclosed CD and on the Internet under:
Certificates (http://www.siemens.com/processinstrumentation/certificates)
A.2 Technical support
Technical Support
If this documentation does not provide complete answers to any technical questions you may have, contact Technical
Support at:
● Support request (http://www.siemens.com/automation/support-request)
● More information about our Technical Support is available at
Technical support (http://www.siemens.com/automation/csi/service)
Internet Service & Support
In addition to our documentation, Siemens provides a comprehensive support solution at:
● Service&Support (http://www.siemens.com/automation/service&support) where you will find support news, support
documents including EDDs and software, and also support from experts.
Additional Support
If you have additional questions about the device, please contact your local Siemens representative.
Find your local contact partner at:
● Partner (http://www.automation.siemens.com/partner)
Documentation for various products and systems is available at:
● Instructions and manuals (http://www.siemens.com/processinstrumentation/documentation)

Siemens SIPART PS2 Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Communication Protocols	HART, PROFIBUS PA, FOUNDATION Fieldbus
Output Pressure	0 to 100% of supply pressure
Hazardous Area Certification	ATEX, IECEx, FM, CSA
Type	Electropneumatic
Input Signal	4-20 mA
Rotation Angle	30° to 90°
Operating Temperature	-40°C to +80°C
Mounting	Linear and rotary actuators
Air Consumption	Typically less than 0.1 kg/h
