Operating Instructions SIPLUS CMS4000 IFN AI-D
SIPLUS CMS4000 IFN AI-D
Operating Instructions, 07/2021, A5E32612781A-AB
29
6.2 Technical Specification
6.2.1 Communication (LNK0…LNK2)
Chart 10 communication (LNK0…LNK2)
Communication Parameter min. typ. max. Unit
Connector three connectors (female) 8-pin (M12)
Data protocol IEEE1394a / b
Data transfer rate 400 Mbps
Galvanic isolation Lines to main electronic no
6.2.2 Power Supply (PWR)
Chart 11 Power supply (PWR)
Specifications at TA=25ºC; Test conditions U
S
= 24V DC (rated Voltage); Analoginputs & Firewireports uncon-
nected;
unless otherwise noted; 1) not allowed; 2) overshoot is leading to demolition;
Power supply Parameter min. typ. max. Unit
Connector
one connector (male)
5-pin (M12)
Supply voltage (DC) 18 24 32 V
Over voltage protection (DC)
permitted for max. 500ms; 2)
35 V
Supply current (DC)
Us = 18V DC;
220 mA
Us = 24V DC;
180 200 mA
Us = 32V DC;
135 mA
Reverse voltage protection
-Us = 0 …-32V DC;
yes
Reverse current
-Is @ -32V DC;
-5 uA
-Is @ -35V DC permitted for max.
500ms; 2)
-100 mA
Voltage low dump
< 18 V DC; 1) not allowed
Power dissipation
Us = 24V DC; 4.3 4.8
W
Shut down (ext. restart) Shut down time
30 35 40
s
Restart time
20 68
s
electrical isolation no
Caution
Voltages (DC) > 32 V could damage the device!
