6.2.8 Construction assembly
Chart 15 Construction assembly
Construction assembly
Case Aluminum
Dimensions with plug
(H x W x D) in mm
210 x 86 x 87 (without mounting)
210 x 86 x 96 (DIN rail mounting)
243 x 86 x 97 (mounting angle)
Mounting Standard:
DIN rail (DIN EN 60715TH35-15)
Optional:
Mounting angle (order number in chap-
ter 7.1)
Minimum distances:
(front, top, bottom) in mm
80, 25, 25
6.2.9 Approval
Chart 16 Approval
Approval Mark
Declaration of conformity
EAC certification
KC certification
RCM certification
