PROFIBUS-DP - Parameterization in DIGSI
74
SIPROTEC PROFIBUS-DP - Communication profile
C53000-L1840-B001-03
Scaling index A predefined scaling possibility (settings of Type, Scaling factor and Zero offset) is
summarized using a Scaling index.
.
Scaling index Type Scaling factor Zero offset
0 Primary value 1.0 0.0
1 Primary value 10.0 0.0
2 Primary value 100.0 0.0
3 Primary value 1000.0 0.0
4 Primary value 10000.0 0.0
5 Secondary value 1000.0 0.0
6 Percentage value 100.0 0.0
7 Secondary value 1.0 0.0
8 Secondary value 10.0 0.0
9 Secondary value 100.0 0.0
Note:
The Scaling indices 7 to 9 are not available for every SIPROTEC device.
