Preface
Hardware required for creating an example project
Table 1- 1 Soft Starter hardware
Order number
Description
3RW4422-1BC44 SIRIUS Soft Starter, values with 400 V, 40 DEG., Standard: 29 A, 15 KW,
inside-delta circuit: 50 A, 22 KW, 200 … 460 V AC, 230 V AC, screw termi-
nals
3RW4900-0KC00 Communication board PROFIBUS for SIRIUS Soft Starter 3RW44
Note on the firmware version
If the soft starter is operated as a DP slave following a Y link with a firm-
ware version <=*E03*, no DPV1 functionality is available. Firmware version
<=*E04* is required for DPV1 functionality following a Y link.
Table 1- 2 Hardware - Automation station 1: Configuration direct on the master system
Order number
Description
6ES7416-3XL04-0AB0 SIMATIC S7-400, CPU 416-3 central processing unit,
e.g. with PROFIBUS DP interface
6ES7407-0KA01-0AA0 SIMATIC S7-400, Power Supply PS 407-10 A, UC 120 / 230 V,
DC 5 V / 10 A
Note
Creating a PCS 7 project
Create the PCS
7 project with the automation station (AS) hardware listed in the table above
this note.
Table 1- 3 Hardware - Automation station 2: Configuration following a Y-link
Order number
Description
6ES7654-2PG67-0XC0
SIMATIC PCS 7 AS417-4-2H for H systems
6ES7407-0KR00-0AA0 SIMATIC S7-400, Power Supply PS 407, 10 A for redundant use
6ES7153-2BA82-0XB0 SIMATIC DP, INTERFACE DP/PA LINK and ET 200M IM153-2 HIGH
FEATURE for H systems
6ES7197-1LB00-0XA0
SIMATIC S7, Y-coupler for building up a Y-link for redundant controllers
