Siemens SIRIUS 3TK2826- 1/2/4 Series User Manual

3ZX1012-0TK28-4EA1 25
2
1
3
5
4
DIN ISO 2380-1A 0,5 x 3
(3TK2826-....1/2/4)
Y22 T2 Y34 74 84 A2
14 24 32 48 58 62
13 23 31 47 57 61
A1 Y12 T1 Y33 T3 1
3TK2826-1BB42
Y22 T2 Y34 73 74 A2
14 24 32 48 58 62
13 23 31 47 57 61
A1 Y12 T1 Y33 T3 1
3TK2826-1CW32
Ia
SET/RESET
SET/RESET
A
B
C
D
A, B, C, D:
Kodiert
Coded
Codé
Cifrado
Codificato
Codificado
kodlanmış
Закодировано
a
b
c
d
3TK2826-1... 3TK2826-2...
∅ 5 ... 6 mm / PZ2
0,8 ... 1,2 Nm
7 ... 10.3 lbf.in
—
1 x 0,5 ... 4,0 mm²
2 x 0,5 ... 2,5 mm²
2 x 0,25 ... 1,5 mm²
2 x 0,5 ... 1,5 mm²
1 x 0,5 ... 2,5 mm²
2 x 0,25 ... 1,5 mm²
— 2 x 0,25 ... 1,5 mm²
AWG
2 x 20 to 14 2 x 24 to 16
10
10
10
Ib
3TK2826-0DA00-0HA0
3RP1903
