Description, device design, dimension drawing
2.2 Connections and terminal designation
Selectivity modules
Manual, 12.2014, C98130-A7579-A1-1-7629
11
*1)
Do not subject the end stop to higher loads
Figure 2-2 Terminal data
The "0 V" connection is only used to supply the internal electronics of the
selectivity module. The 0 V of the connected loads must be routed directly to the power
supply using separate cables!
