Siemens SITOP PSE200U 3A

Selectivity modules
Manual, 12.2014, C98130-A7579-A1-1-7629
45
Technical data
6
Note
Technical data is applicable for a rated input voltage, rated load and +25° C ambient
temperature (if n
othing else is specified).
6.1
Input
6EP1961-2BA00
6EP1961-2BA11
6EP1961-2BA31
6EP1961-2BA21
6EP1961-2BA41
Input
Regulated DC voltage
1*)
Regulated DC voltage
Regulated DC voltage
Input voltage DC/rated value
24 V
24 V
24 V
Input voltage range for DC
22 … 30 V
22 … 30 V
22 … 30 V
Overvoltage strength 35 V; 100 ms 35 V 35 V
Input current at the rated
input voltage 24 V/rated
value
40 A 12 A 40 A
1*)
SITOP select (6EP1961-2BA00) cannot be operated with the DC-UPS module 40 A
(6EP1931-2FC21/-2FC42).
6.2
Output
6EP1961-2BA00
6EP1961-2BA11
6EP1961-2BA31
6EP1961-2BA21
6EP1961-2BA41
Output
Regulated DC voltage
Regulated DC voltage
Regulated DC voltage
Output voltage
Ue - approx. 0.3 V
Ue - approx. 0.2 V
Ue - approx. 0.2 V
Total tolerance Corresponding to the supply-
ing input voltage
Corresponding to the supply-
ing input voltage
Corresponding to the supply-
ing input voltage
Number of outputs
4
4
4
Output current/up to
60°C/each output/rated value
10 A 3 A 10 A
Adjustable response thresh-
old
2 … 10 A 0.5 … 3 A 3 … 10 A
