Description, device design, dimension drawing
2.6 Electronic overload shutdown and reset
Selectivity modules
Manual, 12.2014, C98130-A7579-A1-1-7629
23
Alternatively, a remote reset signal can be used. The non-isolated 24 V input (referred to
terminal "0 V" of the module) at terminal "RST" can be used for this purpose. A reset is
carried out for an input level of > 15 V.
Using a remote reset signal at terminal "RST" all outputs that were shut down electronically
due to an overload are reset at this time. Prerequisite: The output is ready to be reset, i.e.
the electronic overload shutdown occurred longer than 20 s ago (LED of the output flashes
red).
Note
If, after a reset, the cause of the overload is still present, then the output is again
automatically shut down. Before car
rying out a reset, remove the cause of the overload to
