Vibration resistance
The capacitor resistance to vibration corresponds to IEC 68, part 2-6. The following values apply
to the capacitor alone.
Test conditions
Max. test conditions
Test duration 2 h
max. 0,7 g
Frequency range 10 ... 55 Hz
Displacement amplitude 0,75 mm
The connections and the terminals may in󹪞uence the vibration properties. It is necessary to
check the stability when an installed capacitor is exposed to vibration. Irrespective of this, it is
not advised to locate capacitors where vibration amplitude could reach maximum levels in
strongly vibrating appliances.
Appendix
Installation and maintenance instructions for Power Factor Correction (PFC) capacitors
32 Installation Manual, 05/2022, L1V30884033A

Siemens SIVACON Specifications

General

Type	Low-voltage switchgear and controlgear assembly
Modular design	Yes
Form of internal separation	Up to Form 4b
Standards	IEC 61439-1/-2
Installation type	Fixed or withdrawable
