Appendix E - Output Data File Structure
Appendix E: Output Data File
Structure
Table E-1 lists the file name extensions employed by the G50 and the G60 S.
The data shall be output as a file in ASCII code, based on the configuration
described below.
As shown in the figure 3-1, the data consists of sections for the title, header and
for the data’s main body.
Each section consists of its own data string, and the data string consists of a
tag that is enclosed in <> (angle brackets) and the data which belongs to the
tag.
A tag is field name, and its data is the value for that field.
Table E-1 Service Data and File Extensions
Number Data Type Extension
1 Information - Site ist
2 Information - System isy
3 Information - Hardware ihw
4 Information - Software isw
5 Information - Peripheral ipe
–– –
7 Maintenance - Service History shy
8 Maintenance - Log (Key History Log) khl
9 Maintenance - Log (Error Log) erl
Figure E-1 Service Data Structure
Section for the title
<Title>
Title
Section for the header
<Tag>
---data---
Section for the data’s main body
<Tag>
---data---
