2
Configuring intrusion control units
Configuring a Sintony SI410
16
Building Technologies A6V10359489_a_en
CPS Fire Safety 30.09.2016
Adding the intrusion system node
1. Select the new folder.
2. In the left-hand bar, select the Intrusion folder icon .
3. In the menu that appears, select the appropriate icon to add a new intrusion
system node.
a A new node is added to the project structure.
Note:
You can customise the default name of the new node typing in a new name
in the Description field of the Node tab, but do not customise it now since it will be
renamed during the metafile import.
Adding a new SI410 node
Importing the SI410 metafile
1. Select the SI410 node.
2. Select Tools > Import in the Composer menu to start SI410 import.
3. The software presents a browsing window to search for the file to import (the
INI file is expected, see Generating the SI410 metafile [āž™ 13]).
4. Select the import file from the file selection window and click Open.
a In a few moments, the SI410 structure is imported, and the node is represented
in the Composer tree.
Note:
The node is renamed to match the metafile name. To customise the name,
click the node text, type in a new name, and press ENTER.
Note:
After the import procedure, by selecting the
Import
tab, a report page
displays. It contains the detailed logs of the latest import procedure, including any
added or removed objects.
Linking the SI410 to the Communication network (NK8000)
To link the SI410 node to the NK82xx node, do the following:
