Configuring intrusion control units
2
Configuring an SPC4000/SPC5000/SPC6000
23
Building Technologies A6V10359489_a_en
CPS Fire Safety 30.09.2016
Adding a new SPC node
Importing the SPC metafile
1. Select the SPC node.
2. Select Tools > Import in the Composer menu to start the SPC import.
a The software presents a browsing window to search for the file to import.
3. Select the import file from the file selection window and click Open.
a In a few moments, the SPC structure is imported, and the corresponding nodes
are represented in the Composer tree.
Note:
The n
ode is renamed to match the metafile name. To customise the name,
click the node text, type in a new name, and press ENTER.
Note:
After the import procedure, by selecting the
Import
tab, a report page
displays. It contains the detailed logs of the latest import procedure, including any
added or removed objects.
Modifying the imported IP address (optional)
If necessary, you can modify the SPC IP address that was imported (the
modification won’t be affected by subsequent imports):
1. Select the SPC node.
2. Select the Node tab.
3. Enter the IP Address.
Linking the SPC to the Communication network (MM8000/MK8000)
To link the SPC node to the corresponding driver, do the following:
1. Expand the system station folders (Stand-alone or FEP) until you reach the
node that represents the driver.
2. Select the NS8021 - FlexC Driver or the NS8013 - SPC Driver node.
