Introduction
1.6 About Siemens' Transducers
Transducers
8 Compact Operating Instructions, 01/2018, A5E43390688_AA
All transducers incorporate an integral temperature sensor that reports the air temperature at
the transducer to the transceiver. The connection is transparent, in that both the ultrasonic
and temperature components of the transducer use the same leads.
XPS-10, XPS-15/15F,
XPS-30, XRS-5/5C
Transducer with explosion proof
conduit seal
Explosion proof conduit seal
1)
2)
1)
Optional
2)
Perpendicular to Transducer face
Note
Use in hazardous areas
The XPS
-15F and XRS-5C already have a built-in explosion proof conduit seal.
All other transducers need the optional explosion proof conduit seal for use in hazardous
areas.
