TUTORBIT
COSMOGAS
Continued on the next page
6 - USE
Parameter
Description
Access
level
Adjustment
range
Default value
Custom
value
Antistagn hysteresis Solar pump shutdown hysteresis with respect to “Antistagn On Temp”
Installer Value Value
Antifrost Setpoint Antifreeze setpoint on the solar panel sensor. If the sensor falls below this value, the solar pump turns on.
Installer Value Value
Antif hysteresis Solar pump shutdown hysteresis with respect to “Antifrost Setpoint”
Installer Value Value
Solar tank sens Temperature of solar tank sensor
Installer Value Value
Solar Panel Temp Solar panel temperature
Installer Value Value
DT control On or off of the solar pump generated by the temperature delta “Solar pump dT On” and “Solar pump dT On”
Installer Value Value
Antistag. Ctl State of Antistagnation function
Installer Value Value
Pump Solar pump state
Installer Value Value
Heat Pump state
Installer
HP Mode
Heat pump setting for as in Conguration>Heat pump> HP Mode
Installer Value Value
State Heat pump state (Stb = stand-by; Heat = heating; Cool = cooling; DHW= domestic hot water;)
Installer Value Value
Autumn condition If the outdoor temperature is greater than Parameters>Modules>Autumn temp. +1°C, the autumn
condition is activated for which cooling does not work
Installer
Active- NonActive
Q1_Pdc Status of relay Q1 of the HP control
Installer On-Off
Q2_Pdc Status of relay Q2 of the HP control
Installer On-Off
Q3_Pdc Status of relay Q3 of the HP control (OFF when it is heating, ON in DHW)
Installer On-Off
Q4_Pdc N/A
Installer On-Off
Defrost state State of the defrost
Installer Active-NonActive
Forced Ignition
Installer On-Off
Increase Cutoff Increase cutoff setpoint to avoid defrost
Installer Value Value
Mod 1 Modbus State Address readings of the modbus module 1. Visible only if Conguration>System>Modbus Enable=Yes.
Installer
Comm Error MB 1 N/A
Installer Value Value
Unit of measure N/A
Installer °C...°F
Type of device N/A
Installer Slave...Master
Single-burner condition N/A
Installer
2 = Waiting; 9 = In operation; 13 = Fan in post-ventilation; 15 = Pump in post-circulation;
Single-burner state N/A
Installer
0 = Waiting; 16 = Heat demand;
Single-burner err code N/A
Installer
?? = No burner; 255 = No error; See the heat generator’s manual for any other codes;
Heating Setp N/A
Installer Value Value
DHW setpoint N/A
Installer Value Value
