91
TUTORBIT
COSMOGAS
Continued on the next page
6 - USE
Heating mode N/A
Installer
0: Heating with RT (N/A);
1: Heating with outdoor sensor (N/A)
2: Heating with outdoor sensor and RT compensation (N/A);
3: Permanent heating (N/A);
4: Heating controlled by 0-10V input;
DHW mode N/A
Installer
0 = No domestic hot water;
1 = Hot water tank with sensor;
2 = Hot water tank with thermostat;
3 = N/A;
4 = N/A;
5 = N/A;
Burner 1 supply temp N/A
Installer Value Value
Burner 1 return temp N/A
Installer Value Value
Hot water tank temp N/A
Installer Value Value
Burner 1 ue temp N/A
Installer Value Value
Water heater t. Heat generator supply temperature (Measured in the supply manifold)
Installer Value Value
Single-burner power N/A
Installer Value Value
Burner 1 ionisation current N/A
Installer Value Value
Water pressure Heat generator water pressure
Installer Value Value
0-10V input signal 0-10V signal received from the heat generator
Installer Value Value
Burner 1 pump state N/A
Installer
0 = Closed;
100 = Open;
Burner 1 Cond. N/A
Installer
2 = Waiting;
9 = In operation;
13 = Fan in post-ventilation;
15 = Pump in post-circulation;
Burner 1 state N/A
Installer
0 = Waiting;
16 = Heat demand;
Burner 1 err code Burner 1 error code. See the heat generator’s manual for diagnostics
Installer
?? = No burner;
255 = No error;
See the heat generator’s manual for any other
codes;
Burner 1 power Burner 1 power level
Installer Value Value
Burner 2 Cond. N/A
Installer
2 = Waiting;
9 = In operation;
13 = Fan in post-ventilation;
15 = Pump in post-circulation;
Burner 2 state N/A
Installer
0 = Waiting;
16 = Heat request;
Burner 2 err code Burner 2 error code. See the heat generator’s manual for diagnostics
Installer
?? = No burner;
255 = No error;
See the heat generator’s manual for any other
codes;
Burner 2 power Burner 2 power level
Installer Value Value
