A5E32725813 XPS 10/15 F Series Transducer Page 19
Applications
Dryer - Wood Chips
1. Transducer should be mounted perpendicular to slope of wood chips.
2. When used in hazardous areas, the XPS 10 F series transducer (shown)
must use a hazardous seal. This seal is not supplied by Siemens. The XPS
15 F Series transducer comes equipped with a stainless steel coupling
suitable for use in hazardous locations.
drag conveyo
infeed
typical low
level
typical high
level
