Page 4 XPS 10/15 F Series Transducer A5E32725813
Outline & Dimensions
Outline and Dimensions
XPS 10 F Series Transducers
Standard Flange (optional)
Split Flange (optional) Submergence Shield (optional)
Refer to submergence shield instructions
(Siemens’ manual number
7ML19981EG01)
Note:
For the XPS 10 F series transducer, a hazardous seal must be used to
suit hazardous area classification. This seal is not supplied by Siemens.
For more information, refer to page 20.
radiating
face
122mm
(4.8”)
86mm
(3.4”)
122mm
(4.8”)
to suit ANSI
standards
to suit ANSI
standards
128mm
(5.0”)
nominal
152mm
(6.0”)
124mm
(4.9”)
