Description of device terminal
4 Binary input/output Module
The binary input/output module terminal is green 20-wire Phoenix terminal
and ten-way binary inputs and two-way binary outputs are provided. See
table 4 for the terminal definition.
Table 4 Binary input/output module terminal definition description
Serial No. 1 2 3 4 5 6 7 8 9 10
Mark DI1 DI2 DI3 DI4 DI5 DI6 DI7 DI8 DI9 DI10
Serial No. 11 12 13 14 15 16 17 18 19 20
Mark NC 5VGND DO1+ DO1- DO2+ DO2- NC NC NC 5VGND
