Human-machine interface and its operation
Figure 11 CSC-1321 binary output actuator display interface
3.1.4 Version information
Move the cursor to “Version information” menu item on operating condition
menu; press SET button to display current software version number. It will
display the interface as follows:
[1-5]
Software version: 01.20.00
time: Mar 4 2010 16;40;00
Code: DE68 C1A7
Figure 12 CSC-1321 version information display interface
3.2 Setting Setup
To set protocol and channel parameters for each module in the system, press
the “SET” button at “setting setup” menu item and you can see module list
display interface as follows:
[2] 1/1
module 1
module 2
module 3
…
Figure 13 CSC-1321 module list display interface
Press SET at a certain module, protocol lists of this module are shown.
[2-2] 1/1
ProtConf
S.104Protl1 ProtConf
Figure 14 CSC-1321 protocol list display interface
This left column is a name+serial number list of all the protocol configured for
