Human-machine interface and its operation
the module, and the right column is an entrance to check the corresponding
protocol.
Move the cursor to a certain protocol, press SET to enter the interface of
channel display of this protocol, which is shown as follows:
[2-2-1] 1/1
Tcp Server1
Figure 15 CSC-1321 protocol channel display interface
Press SET at the serial interface channel 2 to enter the configuration of this
serial interface channel. More details are seen in 9.3.2.2.2. Channel
Configuration.
3.2.1 Protocol Configuration
Move the cursor to protocol configuration, and press SET to enter the
interface of protocol type:
[2-1-2] 1/1
protocol type: access to protocol 61850
Top:Only to Examine PtoType
Figure 16 CSC-1321 protocol type display interface
This interface is for reference only, and no modification of the protocol can be
made.
3.2.2 Channel Configuration
CSC-1321 system supports many types of channels, each with a different
channel configuration interface.
◆
Serial port configuration
Interface of serial port configuration is shown as follows:
[2-3-2-1] 1/1
To Next Page
