SDG2000X User Manual 127
3.1 Example 1: Generate a Sine Waveform
Generate a sine waveform with 1MHz frequency, 5Vpp amplitude and 1Vdc
offset.
 Steps:
 Set the frequency.
1. Press Waveforms → Sine →Frequency/Period and choose Frequency
which will display in blue color.
2. Input ‗1‘ from the keyboard and choose the unit ‗MHz‘. The frequency is
set to 1MHz.
 Set the Amplitude.
1. Press Amplitude/HighLevel to choose Amplitude which will display in blue
color.
2. Input ‗5‘ from the keyboard and choose the unit ‗Vpp‘. The amplitude is set
to 5Vpp.
 Set the Offset.
1. Press Offset/LowLevel to choose Offset which will display in blue color.
2. Input ‗1‘ from the keyboard and choose the unit ‗Vdc‘. The offset is set to
1Vdc.
When the frequency, amplitude and offset are set, the waveform generated is
shown in Figure 3-1.
