SIGLENT
74 SDG2000X User Manual
2.11 To Set Burst Function
The Burst function can generate versatile waveforms in n this mode. Burst
times can last a specific number of waveform cycles (N-Cycle mode), or when
an external gated signals (Gated mode) is applied. Any waveform (except DC)
may be used as the carrier, but noise can only be used in Gated mode.
Burst Type
SDG2000X provides three burst types including N-Cycle, Infinite and Gated.
The default is N-Cycle.
Table 2-20 Relations among burst type, trigger source and carrier
Sine, Square, Ramp, Pulse, Arbitrary.
Sine, Square, Ramp, Pulse, Arbitrary.
Sine, Square, Ramp, Pulse, Noise, Arbitrary.
N-Cycle
In N-Cycle mode, the generator will output waveform with a specified number
of cycles after receiving the trigger signal. Waveforms that support N-Cycle
burst include sine, square, ramp, pulse and arbitrary.
Press Burst → NCycle → Cycles, and use the numeric keyboard or arrow
keys and knob to input the desired cycles. Set the waveform parameters by
using the operation menu, as shown in Figure 2-38 and Figure 2-39.
