SIGLENT
82 SDG2000X User Manual
device connected.‖, as shown in Figure 2-44. After removing the U-Disk, the
screen will display a prompt message ―USB device removed.‖ And ―USB
Device (0:)‖ in the storage menu will disappear.
Figure 2-44 Storage System
Note:
The SDG2000X can only identify files of which filenames consist of English
letters, number and underscore. If other characters are used, the name may
be displayed in the store and recall interface abnormally.
Browse
Use the knob to shift between the directories or click the corresponding
location on the screen to choose Local (C:) or USB Device (0:). Choose
Browse, press the knob or click the selected folder to open the current
directory.
Use the knob to switch between folder and files under the current directory.
Choose Browse, press the knob or click the selected folder to open the
subdirectory. Choose <up>, then choose Brower or press the knob to
return to the upper level directory.
2.12.2 File Type
