SDG2000X User Manual 139
3.8 Example 8: Generate a Burst Waveform
Generate a burst waveform with 5 cycles. The burst period is 3ms. Use
internal trigger and 0° start phase.
 Steps:
 Set the burst function.
Press Waveforms, and choose the sine waveform as the burst function.
 Set the frequency, amplitude and offset.
1. Press Frequency/Period and choose Frequency which will display in blue
color. Input ‗10‘ from the keyboard and choose the unit ‗kHz‘ to set the
frequency to 10kHz.
2. Press Amplitude/HighLevel to choose Amplitude which will display in blue
color. Input ‗4‘ from the keyboard and choose the unit ‗Vpp‘ to set the
amplitude to 4Vpp.
3. Press Offset/LowLevel to choose Offset which will display in blue color.
Input ‗0‘ from the keyboard and choose the unit ‗Vdc‘ to set the offset to
0Vdc
 Set the burst mode.
Press Burst → NCycle, choose N-Cycle Mode. The default setting of the
source is internal.
 Set the burst period.
Press Burst Period, input ‗3‘ from the keyboard and choose the unit ‗ms‘ to
set the burst period to 3ms.
 Set the start phase.
Press Start Phase, input ‗0‘ from the keyboard and choose the unit ‗°‘ to
set the start phase to 0°.
