Touch Screen Display
SDG2000X can only display parameters and waveform of one channel at a
time. The picture below shows the interface when CH1 chooses AM
modulation of sine waveform. The information displayed may vary depending
on the function selected.
The entire screen of the SDG2000X is a touch screen. You can use your figure
or touch pen to control the instrument. Most functions and selections can be
chosen using the touch screen in a similar manner to the front panel keys and
knob.
Figure 1-4 Touch Screen Display
1. Waveform Display Area
Displays the currently selected waveform of each channel.
2. Channel Status Bar
Indicates the selected status and output configuration of the channels.
1 2
4
3
8 7 6 5
