Sigma Controls MYRIAD DPC User Manual

31
APPENDIX ‘D’
MYRIAD DPC RS485 MODBUS CONNECTIONS
06/06/17
NOTE: MYRIAD MUST BE ORDERED WITH RJ45 MODBUS CONNECTOR
VARIABLES
ADDRESS
DESCRIPTION
RANGE
DISPLAY AS
READ ONLY
40001
PROCESS [MAIN
DISPLAY]
0
-
999
XXX
-
XX.X
-
X.XX
-
.XXX
READ ONLY
40002
SPEED OUTPUT
0
-
1000
XXX.X%
READ ONLY
40003
HMI BAR
0
-
31
COARSE BAR GRAPH
READ ONLY
40004
ALARM CODE
0
-
8
SEE ALARM CODE
READ ONLY
40005
MILLIAMP OUTPUT 1
0
-
2000
XX.XX ma
READ ONLY
40006
MILLIAMP
OUTPUT 2
0
-
2000
XX.XX ma
READ ONLY
40007
MILLIAMP OUTPUT 3
0
-
2000
XX.XX ma
READ ONLY
40008
MILLIAMP OUTPUT 4
0
-
2000
XX.XX ma
READ ONLY
40009
MILLIAMP INPUT 1
0
-
2000
XX.XX ma
READ ONLY
40010
MILLIAMP INPUT 2
0
-
2000
XX.XX ma
READ ONLY
40011
MILLIAMP
INPUT 3
0
-
2000
XX.XX ma
READ ONLY
40012
MILLIAMP INPUT 4
0
-
2000
XX.XX ma
READ ONLY
40013
N/A
READ ONLY
40014
N/A
READ ONLY
40015
N/A
READ ONLY
40016
N/A
READ ONLY
40017
HIGH ALARM SETPOINT
0
-
999
XXX
-
XX.X
-
X.XX
-
.XXX
READ WRITE
40018
HIGH ALARM RE
-
SETPOINT
0
-
999
XXX
-
XX.X
-
X.XX
-
.XXX
READ WRITE
40019
LOW ALARM SETPOINT
0
-
999
XXX
-
XX.X
-
X.XX
-
.XXX
READ WRITE
40020
LOW ALARM RE
-
SETPOINT
0
-
999
XXX
-
XX.X
-
X.XX
-
.XXX
READ WRITE
40021
LEAD ON SETPOINT
0
-
999
XXX
-
XX.X
-
X.XX
-
.XXX
READ WRITE
40022
LEAD OFF SETPOINT
0
-
999
XXX
-
XX.X
-
X.XX
-
.XXX
READ WRITE
40023
LAG ON SETPOINT
0
-
999
XXX
-
XX.X
-
X.XX
-
.XXX
READ WRITE
40024
LAG OFF SETPOINT
0
-
999
XXX
-
XX.X
-
X.XX
-
.XXX
READ WRITE
40025
MIN SPEED OUTPUT
0
-
1000
XXX.X%
READ WRITE
40026
MAX SPEED OUTPUT
0
-
1000
XXX.X%
READ WRITE
40027
MIN SPEED AT PROCESS
VALUE
0
-
999
XXX
-
XX.X
-
X.XX
-
.XXX
READ WRITE
40028
MAX SPEED AT PROCESS
VALUE
0
-
999
XXX
-
XX.X
-
X.XX
-
.XXX
READ WRITE
40029
ALTERNATON MODE
0
-
2
0=OFF,
1=PUMPS OFF, 2
-
TIMED
READ WRITE
