Sigma Controls MYRIAD DPC User Manual

32
40030
LEAD PUMP IS
1 OR 2
X
READ WRITE
40031
LAG PUMP IS
1 OR 2
X
READ WRITE
40032
PID SETPOINT
READ WRITE
40033
PUMP 1 VIRTUAL HOA
0
-
2
0=OFF, 1=HAND, 2
-
AUTO
READ WRITE
40034
PUMP 2 VIRTUAL HOA
0
-
2
0=OFF,
1=HAND, 2
-
AUTO
READ WRITE
BITS
ADDRESS
DESCRIPTION
RANGE
TYPE
READ ONLY
00001
HIGH ALARM
0 = OFF, 1= ON
ALARM
READ ONLY
00002
LOW ALARM
0 = OFF, 1= ON
ALARM
READ ONLY
00003
PUMP 1 FAILED TO RUN
0 = OFF, 1= ON
ALARM
READ ONLY
00004
PUMP 2 FAILED TO
RUN
0 = OFF, 1= ON
ALARM
READ ONLY
00005
PUMP 1 CRITICAL
0 = OFF, 1= ON
ALARM
READ ONLY
00006
PUMP 2 CRITICAL
0 = OFF, 1= ON
ALARM
READ ONLY
00007
SEAL LEAK
0 = OFF, 1= ON
ALARM
READ ONLY
00008
SENSOR FAIL
0 = OFF, 1= ON
ALARM
READ ONLY
00009
PUMP
1 FEEDBACK
0 = OFF, 1= ON
STATUS
READ ONLY
00010
PUMP 2 FEEDBACK
0 = OFF, 1= ON
STATUS
READ ONLY
00011
ALLOCATED BUT UNUSED
0 = OFF, 1= ON
READ ONLY
00012
ALLOCATED BUT UNUSED
0 = OFF, 1= ON
READ ONLY
00013
ALLOCATED BUT UNUSED
0 = OFF, 1= ON
READ
ONLY
00014
ALLOCATED BUT UNUSED
0 = OFF, 1= ON
READ ONLY
00015
ALLOCATED BUT UNUSED
0 = OFF, 1= ON
READ ONLY
00016
ALLOCATED BUT UNUSED
0 = OFF, 1= ON
READ ONLY
00017
SAVE TO EEPROM
0 = OFF, 1= ON
MOMENTARY
READ WRITE
00018
ACKNOWLEDGE
0 = OFF, 1=
ON
MOMENTARY
READ WRITE
00019
RESET
0 = OFF, 1= ON
MOMENTARY
READ WRITE
00020
ALLOCATED BUT UNUSED
0 = OFF, 1= ON
READ WRITE
00021
ALLOCATED BUT UNUSED
0 = OFF, 1= ON
READ WRITE
00022
ALLOCATED BUT UNUSED
0 = OFF, 1= ON
READ WRITE
00023
ALLOCATED
BUT UNUSED
0 = OFF, 1= ON
READ WRITE
00024
ALLOCATED BUT UNUSED
0 = OFF, 1= ON
READ WRITE
WARNING: SETTING VALUES OUT OF LIMITS OR WRITING TO ADDRESSES NOT
MENTIONED HERE CAN CAUSE ERRATIC OPERATION. WRITING TO THESE VALUES
SHOULD ONLY BE DONE BY QUALIFIED PERSONNEL, WITH CAUTION. IT IS
RECOMMENDED TO POLL THESE PARAMETERS IN READ ONLY MODE.
