Sigma Controls MYRIAD DPC User Manual

9
PROGRAMMING & SETUP
The Myriad DPC utilizes ‘plain English’ menu driven setup screens which are intuitive and easily
understood.
MAIN DISPLAY
NOTE: To ‘RETURN’ to the main display from any other screen, scroll to ‘EXIT’ and
press ‘ENTER’.
From the default screen (Fig. 1), push the ‘ENTER’ button to enter the password protected
menus.
Enter the user selected password (factory default is zero) using the ↑ ↓ button and press
‘ENTER’ to access the first programming menu ‘MENU 1’.
NOTE: Programming should begin at ‘MENU 2’. ‘SCALE’ to set the instrument for the correct
input signal from ‘MENU 1’. Use the → ← buttons to highlight the ‘NEXT’ item and press enter to
access ‘MENU 2’.
Process Value
Engineering Units
Alarm Indicator
Level Indicator
Pump Run Indicator
