Main Power Connecon.
To watch “Free on air local channels”, a good TV antenna system needs
to be installed for best picture quality and sound (varies with the area).
Check with your local electronics store for a standard TV Antenna. This can be connected to the TV via
the coaxial/RF Antenna connecon as shown above using the 75 ohm plug.
You can also use the service from your local Cable TV provider and connect as above using a 75 ohm plug
connecon.
Coaxial Cable from antenna or
your Cable TV Provider or from
any other device with a RF signal
(75 ohm Plug)
Connect the power cord correctly as shown.
Cable TV / Antenna Connecon(Coaxtal/RF-1 Input channel).
Antenna in
Port on TV
AUDIO VIDEO
Coax Plug on
Antenna
Cable
AUDIO VIDEO
SIGMAC
LE15AB
9
