C-DIAS PROCESSOR MODULE CCP 531
12.04.2017 Page 27
75
SRAM ERROR
Only EDGE CPUs
An error occurred while initializing,
reading or writing SRAM data.
Possible causes:
- - SRAM configured incorrect-
ly
- - SD card formatted incor-
rectly
- - SD card removed
Solution:
- - evaluate log file
(Event00.log)
- - check configuration
- - format SD card as EDGE
medium with Lasal Class 2
- check SD card
95
USER DEFINED 0
User-definable code.
96
USER DEFINED 1
User-definable code.
97
USER DEFINED 2
User-definable code.
98
USER DEFINED 3
User-definable code.
99
USER DEFINED 4
User-definable code.
100
C_INIT
Initialization start; the configuration is
run.
101
C_RUNRAM
The LASAL project was successfully
started from RAM.
102
C_RUNROM
The LASAL project was successfully
started from ROM.
103
C_RUNTIME
104
C_READY
The CPU is ready for operation.
105
C_OK
The CPU is ready for operation.
106
C_UNKNOWN_CID
An unknown class from a stand-along or
embedded object: unknown base class.
107
C_UNKNOWN_CONSTR
The operating system class cannot be
created; the operating system is proba-
bly wrong.
108
C_UNKNOWN_OBJECT
Reference to an unknown object in an
interpreter program, creation of more
than one DCC080 object.
109
C_UNKNOWN_CHNL
The hardware module number is greater
than 60.
